1. 전기적 사양
(1) Broadband loads
① Return Loss(DC ~ ≤2 GHz) : ≥40 dB
② Return Loss(2 ~ ≤8 GHz) : ≥36 dB
③ Return Loss(8 ~ ≤18 GHz) : ≥34 dB
(2) Adapters
① Return Loss(DC ~ ≤8 GHz) : ≥34 dB
② Return Loss(8 ~ ≤18 GHz) : ≥28 dB
(3) Offset Opens
- Deviation from nominal phase(@18 GHz) : ±1.5°
(4) Offset Shorts
- Deviation from nominal phase(@18 GHz) : ±1.0°

2. 기계적 사양
(1) Broadband loads
- Typical Pin Depth : 0 ~ -50.8 ㎛
(2) Opens
- Typical Pin Depth : 0 ~ -12.7 ㎛
(3) Shorts
- Typical Pin Depth : 0 ~ -12.7 ㎛

2. 환경 사양
(1) Temperature
① Operating : +20 ~ +26 ℃
② Storage : -40 ~ +75 ℃
